As embedded designs grow more complex and signal types become more diverse, traditional oscilloscopes often struggle to keep pace. Engineers need tools that not only capture waveforms but also provide deep visibility, analysis flexibility, and scalability for future-proof test environments.
Enter the Tektronix 5 Series B MSO Mixed Signal Oscilloscope—a powerful, modular platform designed to meet the demands of today’s mixed-signal debugging, validation, and system-level design. Whether you’re working on automotive electronics, high-speed serial protocols, or IoT embedded systems, this scope is redefining what a bench oscilloscope can do.
In this article, we explore what makes the 5 Series MSO a true game-changer—and what you should know before looking up the Tektronix 5 Series MSO price for your next lab upgrade.
Built for Modern Engineering Challenges
The Tektronix 5 Series B MSO isn’t just a minor upgrade—it’s a complete rethinking of how an oscilloscope should function in a mixed-signal environment.
1. Scalable Channel Count
The 5 Series offers up to 8 analog input channels, with FlexChannel® technology allowing each input to function as either an analog channel or 8 digital channels. This means you can configure up to 64 digital channels in a single instrument—ideal for system-level debugging without needing a separate logic analyzer.
2. High-Resolution Touch Display
At the heart of the user experience is a 15.6-inch HD capacitive touch display, making it incredibly intuitive to use. The screen is large enough for side-by-side waveform views, zooms, and measurement analysis—all without feeling cramped.
Performance That Keeps Up With Complexity
Modern signals often involve high-speed buses, varying logic levels, and tightly synchronized analog/digital interactions. The 5 Series MSO is built to keep up.
3. Up to 2 GHz Bandwidth and 16-bit Resolution
Depending on your configuration, the 5 Series B MSO offers up to 2 GHz bandwidth and 16-bit vertical resolution, providing excellent detail for both low-level analog signals and high-speed transients. It also features high waveform capture rates, helping detect rare events and glitches with ease.
4. Massive Acquisition Memory
Standard acquisition memory goes up to 125 Mpoints per channel, with optional upgrades available. That means longer time captures, higher fidelity, and better zooming capability—without compromising signal resolution.
Flexible Analysis for Embedded Systems
This scope is designed for how embedded systems actually work—with analog, digital, and serial data flowing together in complex ways.
5. Protocol Decoding and Serial Bus Support
Out of the box, the 5 Series supports a wide range of serial bus decoding including I2C, SPI, CAN, LIN, FlexRay, RS-232, and more. Optional licenses can extend this to USB, Ethernet, MIL-STD-1553, and others. This makes the scope a one-stop solution for embedded protocol analysis.
6. Advanced Triggering and Search
You’re not just watching signals—you’re interrogating them. With advanced trigger options, waveform search, and segmented memory, the 5 Series helps you isolate hard-to-find events quickly and with minimal setup time.
A Future-Proof, Upgradeable Platform
One of the standout features of the Tektronix 5 Series MSO is its modular, upgradeable architecture.
- Add bandwidth or channels post-purchase via software licenses
- Upgrade record length, protocol options, and analysis tools
- Optional Windows OS mode lets you run third-party apps right from the scope
This modularity means your investment is protected—no need to buy a new scope every time your requirements grow.
Designed for Real Engineers
From automotive labs to university research centers, the 5 Series MSO is gaining popularity because it combines deep functionality with ease of use.
- Built-in web interface allows remote control and viewing
- Compact, quiet form factor fits neatly on crowded benches
- Optional rackmount kits and low-profile models available
Tektronix also backs this scope with world-class support, a growing ecosystem of application software, and regular firmware updates.
Conclusion
If you’re searching for a next-generation mixed-signal oscilloscope that combines power, usability, and long-term value, the Tektronix 5 Series MSO is hard to beat. With features tailored for modern engineering challenges and a scalable platform that grows with your needs, it truly earns its title as a game-changer.
Suppose you’re evaluating your options or comparing the Tektronix 5 Series MSO price. In that case, you can explore detailed configurations, available models, and pricing through eFocus Instruments, your trusted source for electronic test and measurement solutions.
